Lime Mortar Concentrate - PHL 3.5
Lime Mortar Concentrate - PHL 3.5Couldn't load pickup availability
Repointing Coverage
Repointing Coverage
Coverage depends on your wall: brick size, stone pattern, joint width and depth all change how much mortar you need. Coverage is based on concentrate. 1 gallon of concentrate mixed with sand makes about 3.5-4 gallons of mortar. Use the Mortar Estimator below the video on this page to estimate what to order.
Not sure this is the one?
Not sure this is the one?
Send us a photo and the year your home was built, and we'll help you choose. Ask us here.
Restore the timeless beauty and structural integrity of your historic masonry with our PHL 3.5 Lime Mortar.
Preserving a historic building is a labor of love, whether you’re a professional mason or a homeowner dedicated to doing it right. Standard modern cement is often too rigid for older structures, trapping moisture and causing stone or brick to flake and crack over time.
Our PHL 3.5 Lime Mortar Concentrate is designed to respect the original craftsmanship of your building. It offers the breathability of traditional hydraulic lime, but in a flexible concentrate that you mix with local sand. This ensures your repair doesn't just look authentic—it functions exactly the way historic masonry was intended to.
Why PHL 3.5 is the Right Choice
- Made to Breathe: Unlike Portland cement, this pozzolanic lime blend lets your masonry "breathe" and flex, so moisture can move out through the joints instead of being trapped against your brick or stone.
- A Balanced, Moderate Lime: This formula is a balanced middle ground in our lime mortar lineup. It's designed to stay softer and more breathable than the brick around it, which makes it a great fit for many older homes.
- Multiple Sizes Available: Choose from quart, gallon, 5-gallon, and bulk pallet quantities to match the scale of your job, from minor touch-ups to major restorations.
- Visual Accuracy: Choose from White, Gray, Light Buff, Dark Buff, or Dark Red to get a seamless match with your existing joints. Color packs are packaged separately with the mortar so you can add less pigment while mixing to adjust the shade of the mortar.
- User-Friendly: We’ve stripped away the complexity. Just follow the mixing ratios for sand and water to get a smooth, workable consistency that’s ready for the trowel.
Best Uses
- Repointing: Filling in aged or receding joints in historic brick and stone.
- Joint Repair: Filling cracks and gaps in worn mortar joints.
- Heritage Restoration: Maintaining the aesthetic and physical integrity of buildings originally constructed with lime-based mortars.
Mixing Instructions:
- Combine one part PHL 3.5 concentrate with 2.5 to 3 parts clean sand.
- Gradually add water until the desired consistency is achieved.
- Mix thoroughly until the mortar is smooth and homogenous. Mortar is ready to use right away.
Safety Precautions:
- Always wear appropriate safety gear, including gloves and eye protection, when handling mortar.
- Follow the manufacturer's instructions and safety guidelines for proper mixing and application.
Invest in the preservation of your historic masonry with our PHL 3.5 Lime Repointing Mortar. Order your quart or gallon concentrate today and experience the difference that quality, authenticity, and breathability can make.
Watch: mixing a quart batch at home
Estimating tool
Mortar Estimator
Answer a few quick questions and we will suggest a mortar and help you estimate how much to order.
Mortar Estimator
